2.0-inch LCD graphic LCD module 128x64 resolution/12864 graphic dot matrix LCD display 3.3v/MCU interface

2.0-inch LCD graphic LCD module 128x64 resolution/12864 graphic dot matrix LCD display 3.3v/MCU interface

▶ Model: HTM12864-23-11Y-A5P

▶ Type: COG LCD module with board
▶ Display pixels: 128x64
▶ Overall dimensions (mm): 54.6x50.0x9.1
▶ VA window size (mm): 45.2x27.0
▶ AA size (mm): 40.93x24.29
▶ Point spacing (mm): 0.38x0.32
▶ Application: stage controller
▶ Viewing angle: 6H
▶ Backlight: yellow-green light
▶ Pin: 16PIN
▶ Interface: MCU
▶ Working temperature: -20~70℃
▶ Supply voltage: 3.3V
▶ Driver chip: ST7565
