▶ Model: HTM12232Z-01G

▶ Type: Chinese font COB dot matrix module
▶ Display content: 122x32
▶ Overall dimensions (mm): 84.0x44.0x13.9
▶ VA size (mm): 60.0x18.0
▶ AA size (mm): 48.76x14..36
▶ Point spacing mm: 0.41x0.0.36
▶ Product application: Instrumentation
▶Viewing angle: 6H
▶ Backlight type: white light
▶ Number of PINs: 24PIN
▶Interface mode: MCU
▶ Special instructions: Built-in Chinese font library
▶ Working temperature: -20~70℃
▶ Supply voltage: 5.0V
▶ Driver chip: ST7920

Product Consultation Datasheets Download Demo Code
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

Prev Back Next

Related Accessories

Arduino adapter board/suitable for Arduino development board COB/character/graphic dot matrix
Single Row Pin Header Connector
COB 20-pin cable base/character/graphic dot matrix

Product Description
Specification
Attributes

This HOTDISPLAY 122x32 graphic Liquid Crystal Display module shows dark black pixels illuminated on a vibrant yellow/green background. This transflective LCD display is engineered to provide optimal visibility under a wide range of lighting conditions in multiple different environments. In bright sunlight, the display uses its reflective layer to reflect ambient light back to the viewer, making the screen easy to read. In darker settings, a strong backlight is built into the LCD to provide high contrast and display clear graphics to the viewer. This advanced display technology ensures the display is always easy to read, regardless of the lighting conditions.

This graphic LCD display module is fully compatible with Arduino/C8051, which allows for seamless connection with other electronic systems for a wide range of applications. Designed to withstand difficult operating conditions, the HTM12232Z-25W-N5P model operates exceptionally when used within a temperature range from -20 to 70 degrees Celsius. The optimal viewing angle for this LCD is 6:00, it operates at 5V supply voltage, and it’s RoHS compliant.
