  • 2.4 inch smart display module | 240x320 EzUI HMI series | UART TFT LCD Panel

    2.4 inch smart display module HTM-H024A16-UART-A02 Core advantages:


    High-definition display: 2.4 inch smart display module, resolution 240×320 (RGB), normally black panel, NTSC 70% high color gamut, brightness 1500 cd/m², clearly visible under strong light.

    Wide temperature and durability: working temperature -20℃~+70℃, storage temperature -30℃~+80℃, suitable for industrial and harsh environments.

    Flexible interface: supports UART (TTL), RS232, RS485, compatible with multiple communication protocols; convenient resource update (USB/TF card/dedicated PCB).

    Optional touch: three configurations are provided: no touch (NTP), resistive touch (RTP), and capacitive touch (CTP) to meet diverse needs.

    Anti-image retention design: built-in screen saver recommendation (black/dynamic image refresh) to avoid long-term static display and damage to the screen.

    Large-capacity storage: supports 1G-bit/128M-bit resource storage, easily cope with complex interface and multimedia requirements.

    Stable power supply: +5V±0.3V wide voltage design, strong compatibility, low power consumption (typically 500mA).

    Applicable scenarios: 2.4 inch smart display can be used in module industrial HMI, smart device control, medical instruments, outdoor display, etc.

  • Datasheet for Touch Panel,Controller↓

    Name Date Size
    HTM-H024A16-UART-A02 March 03, 2025 70.11KB
  • 024A16.png

  • ITEM

    PARAMETER DESCRIPTION

    UNIT

    TFT series

    HTM-H024A16-UART-A02


    Diagonal size

    2.4”

    Inch

    Resolution

    240x320

    Dot

    Dimensions

    44.00x88.00x4.50

    mm

    Active area (AA)

    36.72x48.96

    mm

    LCD type

    TFT LCD Display

    mm

    Display viewing angle

    Full View


    Aspect ratio

    1:2


    Backlight type

    LED white


    TFT driver IC

    EzUI


    Brightness

    1500

    cd/m2

    Operating temperature

    -20~70℃

    Storage temperature

    -30~70℃
