128x64 dot matrix OLED/2.42-inch green graphics OLED module/monochrome OLED display/SSD1309 controller/SPI

128x64 dot matrix OLED/2.42-inch green graphics OLED module/monochrome OLED display/SSD1309 controller/SPI

▶ Model: HTM-OLED2.42-SPI-G

▶ Size:2.42" diagonal
▶ Display Format:128x64 Pixels
▶ Display Type:Graphic OLED Module
▶ Display Color:Monochrome Green
▶ Outline(mm):72x43x7.02
▶ AA(mm):55.01x27.49
▶ VA(mm):57x29.49
▶ Supply Voltage:3.3V
▶ Interface:SPI
▶ Backlight brightness: 90cd/m2
▶ Compatibility:Arduino
▶ Controller Type:SSD1309
▶ Operating Temperature: -40°C ~ 80°C
▶ Storage Temperature: -40°C ~ 90°C
▶ Added Feature: EMI shielding

Product Consultation Datasheets Download Demo Code
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

No Back Next

Related Accessories

Arduino adapter board/suitable for Arduino development board COB/character/graphic dot matrix
Single Row Pin Header Connector
COB 20-pin cable base/character/graphic dot matrix

Product Description
Specification
Attributes

128x64 dot matrix OLED/2.42-inch green graphics OLED module/monochrome OLED display/SSD1309 controller/SPI
This 128x64 resolution graphical OLED display provides high-contrast viewing and presents bright green graphics against a deep black background. OLED display technology is self-luminous and is designed to provide high visibility and ensure easy reading from any angle in different environments. With this OLED, you can expect the fastest response time. It is a passive matrix display built with the 6800/8080 serial or parallel interface option, fully compatible with Arduino, seamlessly integrates with many different electronic systems, and is suitable for a variety of applications. The display also comes with a 7-pin connector and a built-in SSD1309 controller. The HTM-OLED2.42-SPI-G model is designed to withstand extreme operating conditions and performs well in the temperature range of-40 to 85 degrees Celsius. It requires a 3.3V power supply to operate and is RoHS compliant.

Datasheet for Touch Panel,Controller

Name	Date	Size
TFT-H050A1SVIST4C40	January 01, 1970	270.02KB

ITEM	Parameter Description	UNIT
OLED Model	HTM-OLED2.42-SPI-G
Diagonal Size	2.42”	“
Pixels	128x64	Dot
Appearance Size	72.0X43X7.02	mm
VA Size	57.0X29.49	mm
Active Area (AA)	55.01X27.49	mm
Dot Pitch	0.30X0.30	mm
Supply Voltage	3.3	v
Driver IC	SSD1309
Drive Mode	1/64 duty
Interface	SPI
Type	Oled Module
Display Color	Green
Operating Temperature	-40°C~85°C	℃
Storage Temperature	-40°C~90°C	℃
