15.0"TFT LCD Module | 1024x768 DVI / HDM / DP / VGA TFT Panel | Optical LCD
The 15.0"TFT LCD Module has a resolution of 1024x768, providing a wide viewing angle and excellent color performance, suitable for multi-angle viewing. Its operating voltage range is 12V~24V DC, and it supports multiple interfaces such as DVI, HDMI, DP, VGA, etc. It has strong compatibility and can flexibly adapt to different device requirements.
In terms of display performance, the 15.0"TFT LCD Module ，whose resolution is 1024x768 uses a normally black panel mode (Normally Black). It is necessary to avoid displaying static images for a long time to prevent image retention. It is recommended to refresh the display content regularly or use a black background and dynamic images as a screen saver to extend the life of the screen. At the same time, the display has good environmental adaptability and can work stably in a wide temperature range (the specific operating temperature and storage temperature need to be supplemented according to the specification), suitable for various harsh environments.
The 15.0"TFT LCD Module provides a variety of configuration options, including no touch (NTP), resistive touch (RTP) and capacitive touch (CTP) versions to meet different interaction needs. In addition, the resource update method is flexible, supporting USB, TF card or dedicated download PCB for data update, and optional 1G-Bit, 128M-Bit or 32M-Bit storage capacity, convenient for users to choose according to actual applications.
In terms of mechanical design, the display has a compact structure, a panel size of 304.00mm×228.00mm, and a thickness of 6.00mm, which is suitable for embedded installation and can be widely used in industrial control, medical equipment, commercial retail, consumer electronics and transportation. For example, in industrial automation equipment, its voltage resistance and wide temperature characteristics can ensure stable operation; in medical equipment, high definition and reliability make it suitable for precision display terminals such as monitors; in the commercial field, it can be used for long-term running equipment such as advertising machines and POS machines; and in vehicle-mounted systems, its vibration resistance and temperature adaptability can also meet the needs.
In summary, this 15.0"TFT LCD Module whose resolution is 1024x768 ，is suitable for a variety of high-demand application scenarios with its excellent display effect, flexible configuration and wide environmental adaptability. When using it, users should be careful to avoid displaying static images for a long time, and choose appropriate touch functions and storage configurations according to actual needs to give full play to its performance advantages.
