2.4" 132x64 Graphic LCD Module | STN+ | Blue on Gray | ST7565P | MCU | Arduino

2.4" 132x64 Graphic LCD Module | STN+ | Blue on Gray | ST7565P | MCU | Arduino | 3.3V

▶ Model: HTM13264J-11W

▶ Type: COG LCD module with board
▶ Display pixels: 132x64
▶ Overall dimensions (mm): 68.86x44.15x10.0
▶ VA size (mm): 53.2x31.5
▶ AA size (mm): 48.81x26.21
▶ Point spacing (mm): 0.41x0.38
▶ Application: Industrial Control
▶ Viewing angle: 6H
▶ Backlight/brightness: white light
▶ Pin: FFC-16PIN
▶ Interface mode: MCU
▶ Special instructions: MCU/8BIT
▶ Working temperature: -20~70℃
▶ Supply voltage: 3.3V
▶ Driver chip: ST7565P
