  • 2.6 inch 132x32 Graphic LCD Display Module | FSTN+Gray | 3.3V | ST7565R |RGB Red, Green and Blue Backlight | Arduino

    This HOT Display 132X32 Graphic LCD Display Module displays illuminated dark gray pixels on a red, green and blue background. This fully transparent LCD display is carefully designed to provide optimal visibility in a variety of lighting conditions in many different environments. In bright sunlight, the display uses its anti-polarizer full transparency, the backlight is fully transparent, the display brightness is greatly improved, and the viewer can clearly read the display content. In darker environments, the LCD has a strong backlight built in to provide high contrast and show clear graphics to the viewer. This advanced display technology ensures that the display is always easy to read regardless of the lighting conditions.

    This graphic LCD display module has a built-in negative voltage. It is also fully compatible with Arduino/ C8051 and can be seamlessly connected with other electronic systems for a variety of applications. The HTM13232A model is designed to withstand harsh operating conditions and will not operate properly when used in temperatures ranging from -20 to 70 degrees Celsius. The LCD has an optimal viewing angle of 6:00, operates at 3.3V, and is RoHS compliant.


    Connector Customization:

    Easily modify any connectors on your display to meet your application’s requirements. Our engineers are able to perform soldering for pin headers, boxed headers, right angle headers, and any other connectors your display may require.

    PCB Modifications:

    Choose from a variety of changes to the PCB's shape, size, pinout, and component layout to make it perfect for your application.

    Backlight color customization:

    The module backlight has a variety of combinations to choose from, without backlight or with yellow-green/blue/white/amber/red/RGB backlight options. There are 48 effects. You can click on the customization page for reference.

    Font library customization:

    Provides a variety of font libraries, including English/Japanese, Western Europe, Eastern Europe, Scandinavian Europe, Cyrillic (Russian), Hebrew/Arabic, etc.

    Cable Customization:

    Adjust the length, position, and pinout of your cables or add additional connectors. Get a cable solution that’s precisely designed to make your connections streamlined and secure.


  • 13232A.png

  • Item

    Parameter content

    Unit

    Model

    HTM13232A-35S-A5P


    Resolution

    132× 32

    dots

    Module size

    80.0x 34.99 x 8.0 (MAX)

    mm

    Viewable (VA) area

    64.6 x 18.98

    mm

    Active (AA) area

    60.68 x 14.68

    mm

    Pixel pitch

    0.46 x 0.46

    mm

    IC

    ST7565R


    Applied voltage

    3.3V

    V

    Backlight

    Red green blue


    Display mode

    FSTN(+)


    Drive mode

    1/32 duty cycle


    Product type

    Graphic lcd


    Features

    Transmissive
