Arduino-Character LCD module | 2X16 STN+ Yellow/Green Display with Yellow/Green Backlight

Arduino-Character LCD module | 2X16 STN+ Yellow/Green Display with Yellow/Green Backlight

▶ Model: HTM1602-10-01Y-A5P

▶ Type: Standard COB character LCD module
▶ Display content: 16x2 characters
▶ Overall dimensions (mm): 85.0x29.5x13.1
▶ VA window size (mm): 64.5x15.8
▶ AA size (mm): 55.8x10.64
▶ Point spacing mm: 0.62x0.64
▶ Product application: industrial control
▶ Viewing angle: 6H
▶ Backlight type: yellow/green light
▶ Connection method PIN number: 16PIN
▶ Interface mode: MCU
▶ Special instructions: Anti-static ESD 8KV
▶ Working temperature: -20~70℃
▶ Power supply voltage: 5.0v
▶ Driver chip: ST7066U
