5.0v | 2X40 character monochrome LCD | FSTN positive display | with RGB red, green and blue backlight

5.0v | 2X40 character monochrome LCD | FSTN positive display | with RGB red, green and blue backlight | Arduino display

▶ Model: HTM-4002A-35S-A5P

▶ Type: Standard COB character LCD module
▶ Display content: 20x4 characters
▶ Dimensions (mm): 182.00x33.5x14.0
▶ VA size (mm): 155.1x16.0
▶ AA size (mm): 147.5 x 11.5
▶ Pixel pitch mm: 0.65 x 0.7
▶ Product application: industrial control
▶ Viewing angle: 6H
▶ Backlight type: red/green/blue light
▶ Number of PINs: 16PIN
▶ Interface mode: MCU
▶ Special instructions: Anti-static ESD 8KV
▶ Operating temperature: -20~70℃
▶ Supply voltage: 5.0V
▶ Driver chip:ST7066U

Product Consultation Datasheets Download Demo Code
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

Prev Back Next

Related Accessories

Arduino adapter board/suitable for Arduino development board COB/character/graphic dot matrix
Single Row Pin Header Connector
COB 20-pin cable base/character/graphic dot matrix

Product Description
Specification
Attributes

HTM-4002A-35S-A5P | 5.0v | 2X40 character monochrome LCD | FSTN positive display | with RGB red, green and blue backlight | Arduino display

This compact LCD screen features a thermal display of 40 characters per line. This monochrome LCD ensures optimal readability in different lighting conditions, making it suitable for use with ambient light or its own integrated backlight. The HTM-4002a-35s-a5p features a positive FSTN (Super Twisted Tensile) and you can choose between red, green or blue for the taillight. The LCD has an optimal viewing angle with a 6:00 scene and a wide operating temperature range, from a low temperature of -20 degrees Celsius to a scorching 70 degrees Celsius, making it suitable for use in different environmental conditions. This high-performance display is powered by 5V and is compatible with different development boards, including Arduino. To reinforce our commitment to environmental responsibility, each of our products adheres to the RSP standard, emphasizing its environmentally friendly nature.

Connector Customization:

Easily modify any connectors on your display to meet your application’s requirements. Our engineers are able to perform soldering for pin headers, boxed headers, right angle headers, and any other connectors your display may require.

PCB Modifications:

Choose from a variety of changes to the PCB's shape, size, pinout, and component layout to make it perfect for your application.

Backlight color customization:

The module backlight has a variety of combinations to choose from, without backlight or with yellow-green/blue/white/amber/red/RGB backlight options. There are 48 effects. You can click on the customization page for reference.

Font library customization:

Provides a variety of font libraries, including English/Japanese, Western Europe, Eastern Europe, Scandinavian Europe, Cyrillic (Russian), Hebrew/Arabic, etc.

Cable Customization:

Adjust the length, position, and pinout of your cables or add additional connectors. Get a cable solution that’s precisely designed to make your connections streamlined and secure.

item	Parameter description	Unit
name	HTM-4002A-35S-A5P
Lattice number	40words × 2 lines	dots
Module size	182.0 x 33.5 x 14.0 (MAX)	mm
Visual (VA) area	155.1（W） × 16.0（H）	mm
Valid (AA) area	147.5 （W） × 11.5（H）	mm
Dot (pixel) spacing	0.65 × 0.70mm	mm
IC	ST7066U driver chip
Supply voltage	5.0V	V
Back light	RGB red/green/blue
Display mode	FSTN gray
Drive mode (Duty)	1/16 duty cycle
type	Character LCD
peculiarity	Fully transreflective polarizer
