8.0 inch 1024x600 RGB interface TFT LCD display | IPS full viewing angle vertical TFT | RGB interface | STM32/RK series
This standard 8.0-inch 1024x600 RGB interface TFT LCD display TFT-H080A12WSIHX6N50 has a resolution of 1024x600 pixels, and has a high-quality effect no matter from which direction it is viewed, with a brightness of 600cd/m2. The compact size, 3.3V low-voltage power supply and impressive display quality make this display an excellent choice for projects without touch functions. From a structural point of view, this model has a metal frame, which not only protects the display but also resists interference to a certain extent.
This 8.0-inch 1024x600 RGB interface TFT LCD display uses a 50PIN FPC soft cable connection, and the backlight is separately led out through the power cable to facilitate users to control it separately. It can provide safe and reliable electrical connections, and the connection method of the FPC soft cable makes disassembly easier and easier to operate. This TFT LCD display controller is compatible with a variety of control chips. Different chips can optimize the functions of the display, ensure smooth operation, and accurately present images and graphics. Popular industries for this TFT size include IoT, industrial automation, consumer electronics, test and measurement, and handheld devices. Due to their compatibility with STM32/RK, they are also ideal for DIY or prototype projects. The RGB interface enables fast and efficient communication between the STM32/rk series, ensuring smooth data transmission and real-time updates. Our displays are all RoHS compliant and adhere to strict environmental and safety standards.
This model is a horizontal display version. We also provide a vertical touch version TFT-H080B7HDINV5C30. If the user also needs a version with a driver board, they can choose HTM-H080D13-HI-A01G.
