Color 3.5 inch TFT LCD module display / with capacitive touch screen / 640x480 dots / LVDS / T.B.D controller

Color 3.5 inch TFT LCD module display / with capacitive touch screen / 640x480 dots / LVDS / T.B.D controller

▶ Model: TFT-H035A26VGIST8C30

▶ Type: TFT standard display
▶ Display pixels: 640x480 px
▶ Dimensions (mm): 76.9x63.9x4.8
▶ Display inches: 3.5"
▶ AA size (mm): 70.8x52.56
▶ Application: Industrial control systems, portable electronic devices
▶ Viewing angle: IPS full viewing angle
▶ Backlight/brightness: 850cd/m2
▶ Pin: FPC-30 pin
▶ Interface: LVDS-24 Bit
▶ Special instructions: Anti-static ESD 8KV
▶ Operating temperature: -30~80℃
▶ Supply voltage: 3.3V
▶ Driver chip: T.B.D<TFT>, GT911<CTP>

Product Consultation Datasheets Download Demo Code
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

Prev Back Next

Related Accessories

USB data cable T-port charging data cable/serial screen/adapter board
TFT to HI adapter board

Product Description
Specification
Attributes

Color 3.5 inch TFT LCD module display / with capacitive touch screen / 640x480 dots / LVDS / T.B.D controller
Color 3.5 inch TFT LCD module display / with capacitive touch screen / 640x480 dots / LVDS / T.B.D controller TFT-H035A26VGIST8C30 is a 3.5-inch full-viewing angle display with capacitive touch function. IPS full viewing angle, no matter which angle you watch from, you will get a good display effect. The standard brightness LED backlight is 850 nits, with moderate brightness. This transmissive LCD requires a 3.3 voltage power supply and includes an LVDS-24 Bit interface. It uses a flexible cable FPC cable. It is easy to connect and remove. It has multi-touch and is sensitive and smooth, making it an excellent choice for projects that require simple touch functions. The touch screen will allow users to interact with your application intuitively and create opportunities for interactive menus, control systems, or more attractive user experiences. Some of the industries and applications include industrial control panels, kiosks, point-of-sale (POS) systems, e-readers, information kiosks, ATMs, navigation systems, consumer products, home appliances, and more. Our monitors are RoHS compliant and adhere to strict environmental and safety standards.

ITEM	PARAMETER DESCRIPTION	UNIT
TFT series	TFT-H035A26VGIST8C30
Diagonal size	3.5”	Inch
Resolution	640X480	Dot
Dimensions	76.963.94.8	mm
Active area (AA)	70.8*52.56	mm
LCD type	TFT LCD Display	mm
Display viewing angle	Full View
Aspect ratio	1.2:1
Backlight type	LED white
TFT driver IC	T.B.D<TFT>,GT911<CTP>
Brightness	850	cd/m2
Operating temperature	-30~80℃	℃
Storage temperature	-30~80℃	℃
