5.0 inch 20x4 LCD Character Module | STN Positive Display, Yellow-green Backlight | ST7066 | MCU Interface

5.0 inch 20x4 LCD Character Modules | STN Positive Display, Yellow-green Backlight | ST7066 | MCU Interface | For Arduino

▶ Model: HTM2004C-11Y-A5P

▶ Product type: 5.0 inch 20x4 LCD Character Modules
▶ Display content: 20x4 characters
▶ Dimensions (mm): 146X62.5X12.6
▶ Viewing window size (mm): 123X43
▶ Display size (mm): 118.84x38.47
▶ Dot pitch mm: 0.92x1.1
▶ Product application: industrial control
▶ Viewing angle: 6H
▶ Backlight: yellow-green light
▶ Number of PINs: 16PIN
▶ Interface: MCU
▶ Special instructions: Anti-static ESD 8KV
▶ Operating temperature: -20~70℃
▶ Supply voltage: 5.0v
▶ Driver chip: ST7066U

Product Consultation Datasheets Download Demo Code
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

Prev Back Next

Related Accessories

Arduino adapter board/suitable for Arduino development board COB/character/graphic dot matrix
Single Row Pin Header Connector
COB 20-pin cable base/character/graphic dot matrix

Product Description
Specification
Attributes

5.0 inch 20x4 LCD Character Module | STN Positive Display, Yellow-green Backlight | ST7066 | MCU Interface | For Arduino
The 5.0 inch 20x4 LCD Character Modules is a 4-line, 20-character display with dark grey characters on a yellow-green background. The white LED backlight allows the display to work properly in dark and harsh environments, while this 20x4 transflective LCD offers a wide operating temperature range from -20 to 70 degrees Celsius and comes with an integrated ST7066U controller. The applicable voltage for this product is 5.0v. This product has undergone multiple quality tests and is compatible with a variety of development boards including Arduino.

ITEM	SPECIFICATION	UNIT
Name	HTM-2004C-11Y-A5P
Number of dots	20 × 4	dots
Module size	146.0 x 62.5 x 12.6 (MAX)	mm
VA size	123 x 43.0	mm
AA size	118.84 x 38.7	mm
Pixel pitch	0.65 x 0.7	mm
IC	ST7066
Supply voltage	5V	V
Backlight	Yellow-green
Display mode	STN(+)
Drive mode (Duty)	1/64 duty cycle
Type	Character LCD
Features	Transflective
