5V 4x16 character LCD Module | STN(+) yellow-green side backlit monochrome display | Arduino | MCU interface | ST7066U controller

5V 4x16 character LCD Module | STN(+) yellow-green side backlit monochrome display | Arduino | MCU interface | ST7066U controller | transflective display

▶ Model: HTM-1604B-11Y-A5P

▶ Type: Standard COB character LCD module
▶ Display content: 4x16 characters
▶ Overall dimensions (mm): 87x60x10.4
▶ VA size (mm): 62x27.2
▶ AA size (mm): 56.2x20.8
▶ Point spacing mm: 0.6x0.6
▶ Product application: Instrumentation
▶ Viewing angle: 6H
▶ Backlight: yellow/green
▶ Connection method PIN number: 16pin
▶ Interface mode: MCU
▶ Special instructions: Anti-static ESD 8KV
▶ Working temperature: -20~70℃
▶ Supply voltage: 5.0V
▶ Driver chip:ST7066U

Product Consultation Datasheets Download Demo Code
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

Prev Back Next

Related Accessories

Arduino adapter board/suitable for Arduino development board COB/character/graphic dot matrix
Single Row Pin Header Connector
COB 20-pin cable base/character/graphic dot matrix

Product Description
Specification
Attributes

HTM-1604B-11Y-A5P | 3.3V/5V 4x16 character LCD | STN(+) yellow-green side backlit monochrome display | Arduino | MCU interface | ST7066U controller | transflective display

HOT DISPLAY HTM1604B-11Y-A5P is a 16-character wide, 4-line character LCD module, ST7066U controller, single LED backlight, yellow-green, STN positive display semi-transparent film, black text on a yellow-green background, wide operating temperature range, compliant with Rohs standards , the built-in character set supports English/Japanese text, regarding the complete character set. Choice of pin header connections, 5V or 3.3V power supply, and I2C adapter board for arduino.

It can be easily controlled by MCUs such as 8051 and ARDUINO. It can be used in any embedded system, industrial equipment, security, medical and handheld devices.

Connector Customization:

Easily modify any connectors on your display to meet your application’s requirements. Our engineers are able to perform soldering for pin headers, boxed headers, right angle headers, and any other connectors your display may require.

PCB Modifications:

Choose from a variety of changes to the PCB's shape, size, pinout, and component layout to make it perfect for your application.

Backlight color customization:

The module backlight has a variety of combinations to choose from, without backlight or with yellow-green/blue/white/amber/red/RGB backlight options. There are 48 effects. You can click on the customization page for reference.

Font library customization:

Provides a variety of font libraries, including English/Japanese, Western Europe, Eastern Europe, Scandinavian Europe, Cyrillic (Russian), Hebrew/Arabic, etc.

Cable Customization:

Adjust the length, position, and pinout of your cables or add additional connectors. Get a cable solution that’s precisely designed to make your connections streamlined and secure.

item	Specification conntent	unit
model	HTM1604-11Y-A5P
words × lines	16WORDS × 4 lines	dots
Module size	87x60x10.4 (MAX)	mm
VA size	62.0（W） × 27.2（H）	mm
AA size	56.2x20.8	mm
Point (pixel) spacing	0.60（W） × 0.60（H）mm	mm
IC	ST7066U
Applied voltage	5V	V
backlight	Yellow/green backlight
model	STN+
Drive mode	1/16 duty cycle
type	Character LCD
Polarizer type	Semi Transflective Polarizer
