1.77 inch tft lcd screen st7735 arduino sunlight readable lcd monitor

1.77 inch tft lcd screen st7735 arduino sunlight readable lcd monitor

▶ Model: TFT-H017A3CFTST5N10

▶ Type: 1.77 inch tft lcd screen
▶ Display pixels: 128x160 Px
▶ Overall dimensions (Mm): 34x43.7x2.3
▶ Display inches: 1.77"
▶ Effective size (mm): 28.032x35.04
▶ Application: Handheld testing instruments
▶ Viewing angle: 12H o'clock
▶ Brightness: 850cd/M²
▶ Pin: FPC-10PIN
▶ Interface: SPI
▶ Special instructions: Anti-static ESD 8KV
▶ Working temperature: -20~70℃
▶ Power supply voltage: 2.8V
▶ Driver chip: ST7735

Product Consultation Datasheets Download Demo Code
- Transportation
- Payment
- Taxes
- Ensure
- Return
- Discontinued
Transportation

Our company cooperates with SF Express for domestic express delivery, and DHL for overseas express delivery. You can contact us to inquire about freight and weight to get the latest quotation.

Payment

Online payment is not supported. Transfers can be made through corporate accounts. If a VAT invoice is issued, please contact our sales staff to obtain a corporate account.

Taxes

All products sold on this website do not include tax. If you need a VAT invoice, please contact our sales staff to purchase offline.

Ensure

All products sold on this website have a one-year warranty. If the product is damaged due to improper use by the customer, it will be repaired free of charge. Material cost will be charged.

Return

Products within the warranty period can be returned for repair or replacement. Before returning, please contact our sales staff to confirm the reason for return.

Discontinued

We are committed to long-term production of all products sold on this website. If the IC or panel is discontinued, we will try our best to replace it with compatible materials.

Prev Back Next

Related Accessories

USB data cable T-port charging data cable/serial screen/adapter board
TFT to HI adapter board

Product Description
Specification
Attributes

TFT-H017A3CFTST5N10 | 1.77 inch tft lcd screen st7735 arduino sunlight readable lcd monitor
This 1.77 inch tft lcd screen is suitable for a variety of projects from embedded systems to industrial equipment and handheld devices. It offers a crisp 128x160 pixel resolution and a bright LED backlight brightness of 850 Cd/M2 that is readable in sunlight, ensuring high-quality color image display.
In terms of connection, it uses a 4-wire serial SPI interface and is connected through pin headers to improve communication efficiency with C8051/Arduino/STM32 and other devices. The interface is not only flexible, but also supports fast data transfer, providing the possibility for real-time updates, smooth animations and dynamic visual effects. Although this monitor does not have touch screen functionality, it is compact in size and has low power consumption (using a 2.8V power supply).
In addition, the monitor is RoHS compliant and adheres to strict environmental and safety standards, reflecting the emphasis on environmental protection and user safety. Overall, this monitor combines performance, flexibility, and reliability to suit a variety of modern electronic devices and projects.
